Intake air pressure

≤16 bar

Main gauge range

0～100 mbar

Secondary pressure gauge

0～1.0 bar

Air flow meter range 1

0.65～6.5 m3/h

Air flow meter range 2

5～50 m3/h

Air flow meter range 3

16～160 m3/h

Main air pressure valve quantitative adjustment

0.5～10 bar

Secondary pneumatic valve quantitative adjustment

0～0.5 bar

Intake hose length

3 m

Intake hose connector

DN25 internal thread

Valve mouth

Common size 3

Overall size

900×400×1450 mm
